Product features
+86-756-8818418
Vehicle dimensions | L1600*W1015*H1910mm(For reference only) | Driving method | Servo drive |
Navigation method | Laser navigation | Operating voltage | DC24V |
Walking direction | Forward/backward/left/right turn | Power supply | DC24V100AH |
Load capacity | ≤1500Kg（Customized by project） | Control mode | Single chip microcomputer control |
Walking speed | 0～60m/min(Adjustable) | Operation interface | 5 inch full-color touch screen |
Turning radius | R1130mm | Operation control | Manual/wireless scheduling |
Tracking accuracy | ±20mm | Wireless communication | WIFI protocol |
Positioning accuracy | ±5mm | Site identification | Reflector |
Dragging method | Forklift type | safety protection | Sensor+mechanical anti-collision |
Climbing ability | ≤3°(70%Under load) | Warning method | Signal lights/music |
Road drop | 3mm within | Charging method | Automatic charging/battery replacement |
Road ditch width | 5mm within | Operating cycle | Charge-discharge ratio 1:4 |
